Maximum operating pressure 10 bar, maximum operating temperature 95°C.
SESTA manifolds allow even distribution of the water flow reducing pressure drops and intercepting the flow by means of a built-in manual valve making each circuit autonomous. the centre distances between the outlets are 35 mm to allow easy installation. the processing carried out after the nickel-plating treatment makes SESTA manifolds suitable for the transport of drinking water in compliance with D.M 174/2004.
the brass manifold bodies are low in lead content in compliance with the latest standards: CW617N UNI EN 12165:2016. all seals are made of peroxide EPDM. the mesh is made of green ABS.
a metal plate can be applied to each handle to identify the users and a stamp indicating the type of user. the threads of the main column connections are in G3/4" and 1". the branch pipes can be connected by means of fittings with G1/2" and G3/4" threads.
